如下為我司愛澤工業IZE_Industries本月到貨KUHNKE相關產品，歡迎致電索取樣本資料和產品信息。

KUHNKE電磁閥64.009                                        KUHNKE電磁閥65.111

KUHNKE旋轉電磁閥D29-LOL-F-DS9420      KUHNKE旋轉電磁閥D53-ROL-N

KUHNKE線性電磁閥RM50-F                             KUHNKE線性電磁閥RM32-R-F

KUHNKE電磁閥76.083.98.00                            KUHNKE壓力開關60.073.80.60

KUHNKE電磁閥64系列介紹

Kuhnke 64系列氣動電磁閥采用實心黃銅制造，盡管體積小巧，卻極其堅固耐用。

該系列提供三種安裝方式：管路式（in-line）、直連式和集成塊式（manifold）。

管路式閥體側面設有M5接口，底部配有M3螺紋孔，用于將閥體固定在平面上。

直連式閥體側面設有M5接口，并配有G1/8外螺紋接頭，可直接安裝在閥門、氣缸或其他設備上。

集成塊式閥門既可安裝在現成的模塊化集成塊上，也可根據鉆孔方案直接定制安裝在設備上。

電壓規格包括：12V和24V直流（DC），以及24V、110V和230V交流（AC）。標準線圈功率為DC 4.6W和AC 5.5VA，另提供低功耗線圈選項（DC 1.8W）。

Kuhnke 64 series pneumatic solenoid valves are manufactured using solid brass, and although they are small, they are incredibly robust and durable.

There are three mounting options to choose from; these are in-line, direct, or a manifold mount option.

In-line types are M5 side ported, and M3 threaded on the underside for securing the valve to a flat surface.

Direct mounting types are M5 body ported with a G1/8 male threaded stem designed to fit directly to valves, cylinders or other devices.

Manifold valves are either mounted to an off-the-shelf modular manifold or can be custom attached directly to equipment using a drilling plan.

Voltages are 12, 24V DC: 24, 110 and 230V AC. Standard coil power is DC: 4.6 W and AC: 5.5 VA, low coil power options are DC: 1.8 W.

KUHNKE電磁閥65系列介紹

Kuhnke 65系列氣動電磁閥采用實心黃銅制造，盡管體積小巧，卻極其堅固耐用。

該系列提供三種安裝方式：管路式（in-line）、直裝式（direct mount）和集成塊式（manifold mount）。

管路式閥門采用M5側向接口，底部設有M3螺紋孔，用于將閥門固定在平面上。

直裝式閥門采用M5閥體接口，并配有G1/8外螺紋接頭，可直接安裝在閥門、氣缸或其他設備上。

集成塊式閥門既可安裝在現成的模塊化集成塊上，也可根據鉆孔方案直接定制安裝在設備上。

電壓規格包括：12V和24V直流電（DC），以及24V、110V和230V交流電（AC）。標準線圈功率為DC 4.5W和AC 5VA，另提供DC 1.5W的低功耗選項。

請注意，線圈寬度已從20mm增加至22mm。若要將新閥門安裝在現有集成塊上，可能需要更換集成塊，以適應新閥門增加的線圈寬度。

Kuhnke 65 series pneumatic solenoid valves are manufactured using solid brass, and although they are small, they are incredibly robust and durable.

There are three mounting options to choose from; these are in-line, direct, or a manifold mount option.

In-line types are M5 side ported, and M3 threaded on the underside for securing the valve to a flat surface.

Direct mounting types are M5 body ported with a G1/8 male threaded stem designed to fit directly to valves, cylinders or other devices.

Manifold valves are either mounted to an off-the-shelf modular manifold or can be custom attached directly to equipment using a drilling plan.

Voltages are 12, 24V DC: 24, 110 and 230V AC. Standard coil power is DC: 4.5 W and AC: 5 VA, low coil power options are DC: 1.5 W.

It is important to note that the coil width has increased from 20mm to 22mm. If the new valves fit on an existing manifold, the manifold may need replacing to accommodate the increased coil width of the new valves.

KUHNKE旋轉電磁閥D系列介紹

旋轉電磁閥在通電時，可沿順時針或逆時針方向進行單向快速旋轉運動，并精確到達預設的角度位置。

D系列旋轉電磁閥在軸的兩端均配備滾珠軸承，且軸體無線性位移，從而確保了精確定位、長使用壽命及免維護運行，以低成本實現高性能。

該系列產品支持25°、35°、45°、65°及95°的旋轉角度，提供順時針或逆時針旋轉、單軸或雙軸輸出設計，以及多種復位彈簧配置（或無彈簧選項），可實現高度定制化。

D系列電磁閥的兩側均設有螺紋安裝孔，便于將其固定在平面上。

標準電壓為24V DC，額定負載率為100% ED，連接方式可選引線或插頭；此外，也可根據需求提供其他電壓、彈簧復位選項以及旨在提高扭矩的替代負載率規格。

Rotary solenoids provide unidirectional fast pivotal movement, clockwise or anti-clockwise, to a predefined angular position when energised.

D series rotary solenoids feature ball bearings on both sides of the shaft, with no linear shaft movement to ensure precise positioning for long service life and maintenance-free operation, providing superior performance at a low cost.

Set rotary movements of 25°, 35°, 45°, 65° and 95°, clockwise or anti-clockwise rotation, single or double output shaft design with a choice of return spring position, or without a return spring, enable total customisation of the product.

D series solenoids are provided with threaded holes on either side of the solenoid to secure the device to a flat surface.

Standard voltages are 24V DC, 100%ED rated with flying leads or a plug connection; other voltages, spring return options and alternative duty cycles for increased torque are available on request.

KUHNKE線性電磁閥RM系列介紹

與開放式框架設計相比，采用全封閉線圈結構的圓柱形直線電磁閥能產生更大的作用力，且其封裝式線圈結構提供了高防護性能。

封裝式電磁閥適用于高功率應用場景。其線圈受到妥善保護，能夠適應惡劣或暴露的工作環境；在這些環境中，其他類型的電磁閥設計可能會因受損而導致最終失效。

RM20、RM26 和 RM32 型電磁閥配備雙螺紋軸，通電時可沿單一方向產生推力或拉力；斷電后，內部彈簧會將軸復位至初始位置。該軸不可拆卸。

RM040 至 RM100 型電磁閥提供兩種配置：雙向軸（可提供推力或拉力）或單向軸（僅用于推力應用）。其電磁閥軸可從外殼中拆出，以便進行檢查或輔助安裝。

若要將柱塞（軸）復位至初始位置，需采用機械方式（例如外部安裝彈簧、利用重力或借助自動化工藝流程）。

RM 系列電磁閥采用前端安裝方式。RM20 和 RM26 型電磁閥配有帶螺紋的前端安裝部；RM32 及 RM040 至 RM100 型電磁閥則在兩端設有螺紋孔，以便將其固定在安裝面上。

標準電壓為 24V DC，額定負載率為 100% ED，連接方式可選引線或插頭；如需其他電壓或旨在增大作用力的不同負載率規格，可按需定制。

Cylindrical linear solenoids with a fully enclosed coil produce significantly more force than open-frame designs and provide maximum protection because of their encapsulated coil construction.

Encapsulated solenoids are useful for high-power applications. The coil is protected and suited to arduous or exposed conditions where other solenoid designs would otherwise deteriorate, ultimately leading to failure.

RM20, RM26 and RM32 solenoids come with a double-threaded shaft providing a push or pull force in one direction when energised. An internal spring returns the shaft to its resting position when de-energised. The shaft is not removable.

RM040 to RM100 solenoids come with either a double shaft offering a push force, a pull force, or a single shaft for push-only applications. The solenoid shaft can be removed entirely from the casing for inspection or to assist in mounting the device.

A mechanical solution to return the shaft, for example, an externally mounted spring, gravity, or part of the automated process, is required to return the plunger to a home position.

RM series solenoids are nose-mounted. RM20 and RM26 solenoids come with a threaded nose, and RM32, RM040, to RM100 solenoids are provided with threaded holes at either end of the solenoid to secure the device to a surface.

Standard voltages are 24V DC, 100% ED rated with flying leads or a plug connection; other voltages or alternative duty cycles for increased force are available upon request.

KUHNKE電磁閥76系列介紹

ISO 1 閥門用于控制氣動系統中的壓縮空氣，從而向氣缸、其他閥門及設備發送信號；該類閥門依據歐洲規范設計，統一了安裝孔位、氣流要求及閥體尺寸標準。

ISO 1 閥門提供五通（5-way）功能，支持氣控或電控（通過電磁線圈驅動）方式；電磁線圈的安裝方向可與主閥體呈直列式或垂直式。

可選電壓包括 12V DC、24V/48V/110V AC/DC 以及 230V AC。線圈套入黃銅閥芯桿后，通過螺紋蓋固定，并可連接接線插頭。

結構形式可選座閥或滑閥。

座閥采用 O 型圈、墊片及密封件，其設計旨在提供比滑閥更高的流量。

滑閥采用不銹鋼閥芯與塑料襯套制造；盡管其流量低于座閥，但以使用壽命長而著稱。

ISO 1 valves control compressed air within pneumatic systems to signal cylinders, valves, and other devices, designed to European specifications, standardising mounting holes, airflow requirements and valve body dimensions.

ISO 1 valves are available as a 5-way valve function; they can be pneumatically or electrically controlled by solenoid coils that can be in-line or vertical to the main valve body.

Voltages are 12V DC, 24, 48, 110V AC/DC or 230V AC. Coils slide onto a brass stem; a threaded cap secures the solenoid coil, and a wiring plug can be connected.

Choose between a poppet or spool design.

Poppet valves use O-rings, gaskets and seals designed to offer higher flow rates than spool valves.

Spool valves are manufactured using a stainless steel spool and plastic liner, and although spool valves have lower flow rates than poppet-type designs, they are better known for their long life expectancy.

KUHNKE壓力開關60系列介紹

氣動壓力開關專為檢測氣動系統中的氣壓變化而設計。

它們通常被稱為 PE 轉換器或 PE 開關。氣動壓力開關用于監測應用，以感測氣壓的變化。它們將這些氣壓變化轉換為電信號，進而向其他設備發送信號。

不可調節的微型壓力開關適用于電池供電的計時器或計數器，為各種計時或計數應用提供了一種簡單且低成本的解決方案。典型應用場景包括定期更換過濾器，以及氣動工具和隔膜泵的維護保養。

可調節壓力開關配有轉換觸點，當達到設定壓力時，觸點會接通或斷開電路；可選的設定范圍為 0.5 至 4 bar 或 3 至 8 bar。

Pneumatic pressure switches are designed to detect changes in air pressure in pneumatic systems.

They are often referred to as PE converters or PE switches. Pneumatic pressure switches are used in monitoring applications to sense changes in air pressure. They convert these changes in air pressure into electrical signals, which are then used to signal other devices.

The non-adjustable miniature pressure switch is suitable for battery-operated timers or counters. It provides a simple, low-cost solution for a range of timing or counting applications. Typical examples include regular filter changing, servicing of air tools and diaphragm pumps.

Adjustable pressure switches include changeover contacts that make or break a circuit when the set pressure is reached; available setting ranges are 0.5 to 4 bar or 3 to 8 bar.

KUHNKE產品常用型號：

KUHNKE 60.073.40.01

KUHNKE 60.073.80.01

KUHNKE 60.073.80.60

KUHNKE 60.060.01

KUHNKE 64.009

KUHNKE 64.008

KUHNKE 64.056

KUHNKE 64.055

KUHNKE 64.025

KUHNKE 64.024

KUHNKE 64.073

KUHNKE 64.072

KUHNKE 64.017

KUHNKE 64.016

KUHNKE 64.065

KUHNKE 64.066

KUHNKE 64.001

KUHNKE 64.002

KUHNKE 64.054

KUHNKE 64.053

KUHNKE 64.011

KUHNKE 64.015

KUHNKE 64.014

KUHNKE 65.113

KUHNKE 65.114

KUHNKE 65.233

KUHNKE 65.234

KUHNKE 65.111

KUHNKE 65.112

KUHNKE 65.171

KUHNKE 65.172

KUHNKE 65.231

KUHNKE 65.232

KUHNKE 65.261

KUHNKE 65.119

KUHNKE 65.12

KUHNKE 65.175

KUHNKE 65.176

KUHNKE 65.127

KUHNKE 65.128

KUHNKE 65.173

KUHNKE 65.174

KUHNKE 65.235

KUHNKE 65.236

KUHNKE 65.271

KUHNKE 76.087.71.41

KUHNKE 76.083.71.41

KUHNKE 76.087.71.42

KUHNKE 76.083.71.42

KUHNKE 76.087.71.47

KUHNKE 76.083.71.47

KUHNKE 76.084.71.28

KUHNKE 76.084.71.38

KUHNKE 76.087.91.00

KUHNKE 76.083.91.00

KUHNKE 76.087.92.00

KUHNKE 76.083.92.00

KUHNKE 76.087.97.00

KUHNKE 76.083.97.00

KUHNKE 76.087.98.00

KUHNKE 76.083.98.00

KUHNKE D94-BOL-N 24V=100%ED

KUHNKE D53-ROL-N-24VDC 100%ED

KUHNKE D53-LOR-N-24VDC 100% ED

KUHNKE D29-LOL-F-DS9420 24VDC 100%ED

KUHNKE RM20-R-F-24VDC 100%ED

KUHNKE RM26-R-F24VDC 100%ED

KUHNKE RM32-R-F24VDC 100%ED

KUHNKE RM040-W-OROR-N-24VDC 100%ED

KUHNKE RM050-W-OROR-N-24VDC 100%ED

KUHNKE RM060-W-OROR-N-24VDC 100%ED

KUHNKE RM070-W-OROR-N-24VDC 100%ED

KUHNKE RM080-W-OROR-N-24VDC 100%ED

KUHNKE RM090-W-OROR-N-24VDC 100%ED

KUHNKE RM100-W-OROR-N-24VDC 100%ED

如果您需要完整的KUHNKE的相關技術咨詢，請隨時致電愛澤工業，或者訪問網站,我們將盡全力解決您的問題。

If you have any question for KUHNKE，Please feel free to communicate with us and we will do our best to solve your problem.
