BIJUR DELIMON設計和制造各種流體分配產品和系統。這些系統的范圍從簡單的單點油脂給料器到復雜的自動系統，這些系統將油或油脂分配到數百個潤滑點。

主營產品

BIJUR DELIMON水泵

BIJUR DELIMON壓力開關

BIJUR DELIMON潤滑產品

BIJUR DELIMON氣動桶泵

BIJUR潤滑器FZA系列技術參數

BIJUR潤滑器FZA系列介紹

FZ-A 潤滑器主要用于直接供油應用，至多可服務 12 個潤滑點。潤滑器配有泵體，泵體由單排出口（1-6）或雙排出口（1-12）組成。每個出口或每組出口的排量可通過位于泵體頂部的調節主軸進行調節。通過在潤滑器下游安裝漸進式分配器，可服務 12 個以上的潤滑點。FZ-A 潤滑器通常由法蘭安裝電機驅動，或通過棘輪或旋轉驅動器通過潤滑機器驅動。活塞柱塞的最大允許速度為旋轉驅動潤滑器的 10 rpm 和棘輪驅動的 6 rpm。提供多種傳動比，使該潤滑器能夠適應各種機器要求。

• 堅固耐用的組件，適用于惡劣和嚴苛的應用

• 油脂攪拌器和儲油槽楔板確保將油脂輸送到活塞腔

• 適應需要潤滑的機器的各種驅動速度，無需額外的控制系統

• 利用超聲波高/低液位開關和填充口連接實現自動補給功能

• 適用于漸進式系統和齒輪噴霧系統

The FZ-A Lubricator is primarily designed for direct feed applications for servicing up to 12 lubrication points. The lubricators are supplied with pump bodies comprising either a single row of outlets (1-6) or a double row of outlets (1-12). Discharge is adjustable for each outlet or set of outlets via adjusting spindles located at the top of the pump body. Service to more than 12 lubrication points can be accomplished by installing progressive dividers downstream of the lubricator. FZ-A lubricators are typically driven by a flange mounted motor or via the machine being lubricated through either a ratchet or rotary drive. Maximum permissible speed of the piston plunger is 10 rpm for rotary drive lubricators and 6 rpm for ratchet drive. A wide range of transmission ratios are available making this lubricator adaptable to meet a diversity of machine requirements.

• Robust components for harsh and severe applications

• Grease agitator and reservoir wedge plate assures delivery of grease to piston chamber

• Adaptability to various drive speeds of the machine to be lubricated, eliminating the need for additional control systems

• Automatic refill capabilities utilizing ultrasonic high/low level switch and fill port connection

• Adaptable to progressive systems and gear spray systems

BIJUR潤滑器FZA系列其他常用型號：

BIJUR FZA1A14AL17

BIJUR FZA1A23AL17

BIJUR FZA1A29AA59X01

BIJUR FZA2A23AL17

BIJUR FZA3A23AL17

BIJUR FZA4A23AL17

BIJUR FZA6A29AA00

BIJUR FZA01A23AL17

BIJUR FZA02A23AL17

BIJUR FZA04A23AL17

BIJUR LUBRICATOR NEW + ORIGINAL+ ONE YEAR WARRANTY

愛澤工業成立于2010年，定位于向制造工業提供制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。

如果有任何關于BIJUR潤滑器FZA04A23AL17的疑問，請隨時與我們溝通。我們將盡全力解決您的問題。

If you have any question for BIJUR products, Please feel free to communicate with us and we will do our best to solve your problem.

BIJUR潤滑器FZA系列FZA04A23AL17技術參數及介紹
